ATCR Hold Service

The storage backend component of ATCR (ATProto Container Registry)

Overview

Hold Service is the storage backend component of ATCR. It enables BYOS (Bring Your Own Storage) - users can store their own container image layers in their own S3, Storj, Minio, or filesystem storage. Each hold runs as a full ATProto user with an embedded PDS, exposing both standard ATProto sync endpoints and custom XRPC endpoints for OCI multipart blob uploads.

What Hold Service Does

Hold Service is the storage layer that:

Bring Your Own Storage (BYOS) - Store your own container image layers in your own S3, Storj, Minio, or filesystem
Embedded ATProto PDS - Each hold is a full ATProto user with its own DID, repository, and identity
Custom XRPC Endpoints - OCI-compatible multipart upload endpoints (io.atcr.hold.*) for blob operations
Presigned URL Generation - Creates time-limited S3 URLs for direct client-to-storage transfers (~99% bandwidth reduction)
Crew Management - Controls access via captain and crew records stored in the hold’s embedded PDS
Standard ATProto Sync - Exposes com.atproto.sync.* endpoints for repository synchronization and firehose
Multi-Backend Support - Works with S3, Storj, Minio, filesystem, Azure, GCS via distribution’s driver system
Bluesky Integration - Optional: Posts container image push notifications from the hold’s identity to Bluesky

The ATCR Ecosystem

Hold Service is the storage backend of a multi-component architecture:

AppView - Registry API + web interface
Hold Service (this component) - Storage backend with embedded PDS
Credential Helper - Client-side tool for ATProto OAuth authentication

Data flow:

Docker Client → AppView (resolves identity) → User's PDS (stores manifest)
                    ↓
              Hold Service (generates presigned URL)
                    ↓
              S3/Storj/etc. (client uploads/downloads blobs directly)

Manifests (small JSON metadata) live in users’ ATProto PDS, while blobs (large binary layers) live in hold services. AppView orchestrates the routing, and hold services provide presigned URLs to eliminate bandwidth bottlenecks.

When to Run Your Own Hold

Most users can push to the default hold at https://hold01.atcr.io - you don’t need to run your own hold.

Run your own hold if you want to:

Control where your container layer data is stored (own S3 bucket, Storj, etc.)
Manage access for a team or organization via crew membership
Reduce bandwidth costs by using presigned URLs for direct S3 transfers
Run a shared hold for a community or project
Maintain data sovereignty (keep blobs in specific geographic regions)

Prerequisites:

S3-compatible storage (AWS S3, Storj, Minio, UpCloud, etc.) OR filesystem storage
(Optional) Domain name with SSL/TLS certificates for production
ATProto DID for hold owner (get from: https://bsky.social/xrpc/com.atproto.identity.resolveHandle?handle=yourhandle.bsky.social)

Quick Start

Using Docker Compose

The fastest way to run Hold service with S3 storage:

# Clone repository
git clone https://tangled.org/@evan.jarrett.net/at-container-registry
cd atcr

# Copy and configure environment
cp .env.hold.example .env.hold
# Edit .env.hold - set HOLD_PUBLIC_URL, HOLD_OWNER, S3 credentials (see Configuration below)

# Start hold service
docker-compose -f docker-compose.hold.yml up -d

# Verify
curl http://localhost:8080/.well-known/did.json

Minimal Configuration

At minimum, you must set:

# Required: Public URL (generates did:web identity)
HOLD_PUBLIC_URL=https://hold.example.com

# Required: Your ATProto DID (for captain record)
HOLD_OWNER=did:plc:your-did-here

# Required: Storage driver type
STORAGE_DRIVER=s3

# Required for S3: Credentials and bucket
AWS_ACCESS_KEY_ID=your-access-key
AWS_SECRET_ACCESS_KEY=your-secret-key
S3_BUCKET=your-bucket-name

# Recommended: Database directory for embedded PDS
HOLD_DATABASE_DIR=/var/lib/atcr-hold

See Configuration Reference below for all options.

Configuration Reference

Hold Service is configured entirely via environment variables. Load them with:

source .env.hold
./bin/atcr-hold

Or via Docker Compose (recommended).

Server Configuration

`HOLD_PUBLIC_URL` ⚠️ REQUIRED

Default: None (required)
Description: Public URL of this hold service. Used to generate the hold’s did:web identity. The hostname becomes the hold’s DID.
Format: https://hold.example.com or http://127.0.0.1:8080 (development)
Example: https://hold01.atcr.io → DID is did:web:hold01.atcr.io
Note: This URL must be reachable by AppView and Docker clients

`HOLD_SERVER_ADDR`

Default: :8080
Description: HTTP listen address for XRPC endpoints
Example: :8080, :9000, 0.0.0.0:8080

`HOLD_PUBLIC`

Default: false
Description: Allow public blob reads (pulls) without authentication. Writes always require crew membership.
Use cases:
- true: Public registry (anyone can pull, authenticated users can push if crew)
- false: Private registry (authentication required for both push and pull)

Storage Configuration

`STORAGE_DRIVER`

Default: s3
Options: s3, filesystem
Description: Storage backend type. S3 enables presigned URLs for direct client-to-storage transfers (~99% bandwidth reduction). Filesystem stores blobs locally (development/testing).

S3 Storage (when `STORAGE_DRIVER=s3`)

`AWS_ACCESS_KEY_ID` ⚠️ REQUIRED for S3

Description: S3 access key ID for authentication
Example: AKIAIOSFODNN7EXAMPLE

`AWS_SECRET_ACCESS_KEY` ⚠️ REQUIRED for S3

Description: S3 secret access key for authentication
Example: wJalrXUtnFEMI/K7MDENG/bPxRfiCYEXAMPLEKEY

`AWS_REGION`

Default: us-east-1
Description: S3 region
AWS regions: us-east-1, us-west-2, eu-west-1, etc.
UpCloud regions: us-chi1, us-nyc1, de-fra1, uk-lon1, sg-sin1

`S3_BUCKET` ⚠️ REQUIRED for S3

Description: S3 bucket name where blobs will be stored
Example: atcr-blobs, my-company-registry-blobs
Note: Bucket must already exist

`S3_ENDPOINT`

Default: None (uses AWS S3)
Description: S3-compatible endpoint URL for non-AWS providers
Storj: https://gateway.storjshare.io
UpCloud: https://[bucket-id].upcloudobjects.com
Minio: http://minio:9000
Note: Leave empty for AWS S3

Filesystem Storage (when `STORAGE_DRIVER=filesystem`)

`STORAGE_ROOT_DIR`

Default: /var/lib/atcr/hold
Description: Directory path where blobs will be stored on local filesystem
Use case: Development, testing, or single-server deployments
Note: Presigned URLs are not available with filesystem driver (hold proxies all blob transfers)

Embedded PDS Configuration

`HOLD_DATABASE_DIR`

Default: /var/lib/atcr-hold
Description: Directory path for embedded PDS carstore (SQLite database). Carstore creates db.sqlite3 inside this directory.
Note: This must be a directory path, NOT a file path. If empty, embedded PDS is disabled (not recommended - hold authorization requires PDS).

`HOLD_KEY_PATH`

Default: {HOLD_DATABASE_DIR}/signing.key
Description: Path to hold’s signing key (secp256k1). Auto-generated on first run if missing.
Note: Keep this secure - it’s used to sign ATProto commits in the hold’s repository

Access Control

`HOLD_OWNER`

Default: None
Description: Your ATProto DID. Used to create the captain record and add you as the first crew member with admin role.
Get your DID: https://bsky.social/xrpc/com.atproto.identity.resolveHandle?handle=yourhandle.bsky.social
Example: did:plc:abc123xyz789
Note: If set, the hold will initialize with your DID as owner on first run

`HOLD_ALLOW_ALL_CREW`

Default: false
Description: Allow any authenticated ATCR user to write to this hold (treat all as crew)
Security model:
- true: Any authenticated user can push images (useful for shared/community holds)
- false: Only hold owner and explicit crew members can push (verified via crew records in hold’s PDS)
Use cases:
- Public registry: HOLD_PUBLIC=true, HOLD_ALLOW_ALL_CREW=true
- ATProto users only: HOLD_PUBLIC=false, HOLD_ALLOW_ALL_CREW=true
- Private hold: HOLD_PUBLIC=false, HOLD_ALLOW_ALL_CREW=false (default)

Bluesky Integration

`HOLD_BLUESKY_POSTS_ENABLED`

Default: false
Description: Create Bluesky posts when users push container images. Posts include image name, tag, size, and layer count.
Note: Posts are created from the hold’s embedded PDS identity (did:web). Requires hold to be crawled by Bluesky relay.
Enable relay crawl: ./deploy/request-crawl.sh hold.example.com

`HOLD_PROFILE_AVATAR`

Default: https://imgs.blue/evan.jarrett.net/1TpTOdtS60GdJWBYEqtK22y688jajbQ9a5kbYRFtwuqrkBAE
Description: URL to download avatar image for hold’s Bluesky profile. Downloaded and uploaded as blob during bootstrap.
Note: Avatar is stored in hold’s PDS and displayed on Bluesky profile

Advanced Configuration

`TEST_MODE`

Default: false
Description: Enable test mode (skips some validations). Do not use in production.

`DISABLE_PRESIGNED_URLS`

Default: false
Description: Force proxy mode even with S3 configured (for testing). Disables presigned URL generation and routes all blob transfers through the hold service.
Use case: Testing, debugging, or environments where presigned URLs don’t work

XRPC Endpoints

Hold Service exposes two types of XRPC endpoints:

ATProto Sync Endpoints (Standard)

GET /.well-known/did.json - DID document (did:web resolution)
GET /xrpc/com.atproto.sync.getRepo - Download full repository as CAR file
GET /xrpc/com.atproto.sync.getBlob - Get blob or presigned download URL
GET /xrpc/com.atproto.sync.subscribeRepos - WebSocket firehose for real-time events
GET /xrpc/com.atproto.sync.listRepos - List all repositories (single-user PDS)
GET /xrpc/com.atproto.repo.describeRepo - Repository metadata
GET /xrpc/com.atproto.repo.getRecord - Get record by collection and rkey
GET /xrpc/com.atproto.repo.listRecords - List records in collection
POST /xrpc/com.atproto.repo.deleteRecord - Delete record (owner/crew admin only)

OCI Multipart Upload Endpoints (Custom)

POST /xrpc/io.atcr.hold.initiateUpload - Start multipart upload session
POST /xrpc/io.atcr.hold.getPartUploadUrl - Get presigned URL for uploading a part
PUT /xrpc/io.atcr.hold.uploadPart - Direct buffered part upload (alternative to presigned URLs)
POST /xrpc/io.atcr.hold.completeUpload - Finalize multipart upload
POST /xrpc/io.atcr.hold.abortUpload - Cancel multipart upload
POST /xrpc/io.atcr.hold.notifyManifest - Notify hold of manifest upload (creates layer records, Bluesky posts)

Authorization Model

Hold Service uses crew membership records in its embedded PDS for access control:

Read Access (Blob Downloads)

Public Hold (HOLD_PUBLIC=true):

Anonymous users: ✅ Allowed
Authenticated users: ✅ Allowed

Private Hold (HOLD_PUBLIC=false):

Anonymous users: ❌ Forbidden
Authenticated users with crew membership: ✅ Allowed
Crew must have blob:read permission

Write Access (Blob Uploads)

Regardless of HOLD_PUBLIC setting:

Hold owner (from captain record): ✅ Allowed
Crew members with blob:write permission: ✅ Allowed
Non-crew authenticated users: Depends on HOLD_ALLOW_ALL_CREW
- HOLD_ALLOW_ALL_CREW=true: ✅ Allowed
- HOLD_ALLOW_ALL_CREW=false: ❌ Forbidden

Authentication Method

AppView uses service tokens from user’s PDS to authenticate with hold service:

AppView calls user’s PDS: com.atproto.server.getServiceAuth with hold DID
User’s PDS returns a service token scoped to the hold DID
AppView includes service token in XRPC requests to hold
Hold validates token and checks crew membership in its embedded PDS

Deployment Scenarios

Personal Hold (Single User)

Your own storage for your images:

# Hold config
HOLD_PUBLIC_URL=https://hold.alice.com
HOLD_OWNER=did:plc:alice-did
HOLD_PUBLIC=false           # Private (only you can pull)
HOLD_ALLOW_ALL_CREW=false   # Only you can push
HOLD_DATABASE_DIR=/var/lib/atcr-hold

# S3 storage
STORAGE_DRIVER=s3
AWS_ACCESS_KEY_ID=your-key
AWS_SECRET_ACCESS_KEY=your-secret
S3_BUCKET=alice-container-registry
S3_ENDPOINT=https://gateway.storjshare.io  # Using Storj

Shared Hold (Team/Organization)

Shared storage for a team with crew members:

# Hold config
HOLD_PUBLIC_URL=https://hold.acme.corp
HOLD_OWNER=did:plc:acme-org-did
HOLD_PUBLIC=false           # Private reads (crew only)
HOLD_ALLOW_ALL_CREW=false   # Explicit crew membership required
HOLD_DATABASE_DIR=/var/lib/atcr-hold

# S3 storage
STORAGE_DRIVER=s3
AWS_ACCESS_KEY_ID=your-key
AWS_SECRET_ACCESS_KEY=your-secret
S3_BUCKET=acme-registry-blobs

Then add crew members via XRPC or hold PDS records.

Public Hold (Community Registry)

Open storage allowing anyone to push and pull:

# Hold config
HOLD_PUBLIC_URL=https://hold.community.io
HOLD_OWNER=did:plc:community-did
HOLD_PUBLIC=true            # Public reads (anyone can pull)
HOLD_ALLOW_ALL_CREW=true    # Any authenticated user can push
HOLD_DATABASE_DIR=/var/lib/atcr-hold

# S3 storage
STORAGE_DRIVER=s3
AWS_ACCESS_KEY_ID=your-key
AWS_SECRET_ACCESS_KEY=your-secret
S3_BUCKET=community-registry-blobs

Development/Testing

Local filesystem storage for testing:

# Hold config
HOLD_PUBLIC_URL=http://127.0.0.1:8080
HOLD_OWNER=did:plc:your-test-did
HOLD_PUBLIC=true
HOLD_ALLOW_ALL_CREW=true
HOLD_DATABASE_DIR=/tmp/atcr-hold

# Filesystem storage
STORAGE_DRIVER=filesystem
STORAGE_ROOT_DIR=/tmp/atcr-hold-blobs

Production Deployment

For production deployments with:

SSL/TLS certificates
S3 storage with presigned URLs
Proper access control
Systemd service files
Monitoring

See deploy/README.md for comprehensive production deployment guide.

Quick Production Checklist

Before going to production:

Set HOLD_PUBLIC_URL to your public HTTPS URL
Set HOLD_OWNER to your ATProto DID
Configure S3 storage (STORAGE_DRIVER=s3)
Set AWS_ACCESS_KEY_ID, AWS_SECRET_ACCESS_KEY, S3_BUCKET, S3_ENDPOINT
Set HOLD_DATABASE_DIR to persistent directory
Configure HOLD_PUBLIC and HOLD_ALLOW_ALL_CREW for desired access model
Configure SSL/TLS termination (Caddy/nginx/Cloudflare)
Verify DID document: curl https://hold.example.com/.well-known/did.json
Test presigned URLs: Check logs for “presigned URL” messages during push
Monitor crew membership: curl https://hold.example.com/xrpc/com.atproto.repo.listRecords?repo={holdDID}&collection=io.atcr.hold.crew
(Optional) Enable Bluesky posts: HOLD_BLUESKY_POSTS_ENABLED=true
(Optional) Request relay crawl: ./deploy/request-crawl.sh hold.example.com

Configuration Files Reference

.env.hold.example - All available environment variables with documentation
deploy/.env.prod.template - Production configuration template (includes both AppView and Hold)
deploy/README.md - Production deployment guide
AppView Documentation - Registry API server setup
BYOS Architecture - Bring Your Own Storage technical design

evan.jarrett.net / atcr-hold

Pull this image

Overview

ATCR Hold Service

Overview

What Hold Service Does

The ATCR Ecosystem

When to Run Your Own Hold

Quick Start

Using Docker Compose

Minimal Configuration

Configuration Reference

Server Configuration

HOLD_PUBLIC_URL ⚠️ REQUIRED

HOLD_SERVER_ADDR

HOLD_PUBLIC

Storage Configuration

STORAGE_DRIVER

S3 Storage (when STORAGE_DRIVER=s3)

AWS_ACCESS_KEY_ID ⚠️ REQUIRED for S3

AWS_SECRET_ACCESS_KEY ⚠️ REQUIRED for S3

AWS_REGION

S3_BUCKET ⚠️ REQUIRED for S3

S3_ENDPOINT

Filesystem Storage (when STORAGE_DRIVER=filesystem)

STORAGE_ROOT_DIR

Embedded PDS Configuration

HOLD_DATABASE_DIR

HOLD_KEY_PATH

Access Control

HOLD_OWNER

HOLD_ALLOW_ALL_CREW

Bluesky Integration

HOLD_BLUESKY_POSTS_ENABLED

HOLD_PROFILE_AVATAR

Advanced Configuration

TEST_MODE

DISABLE_PRESIGNED_URLS

XRPC Endpoints

ATProto Sync Endpoints (Standard)

OCI Multipart Upload Endpoints (Custom)

Authorization Model

Read Access (Blob Downloads)

Write Access (Blob Uploads)

Authentication Method

Deployment Scenarios

Personal Hold (Single User)

Shared Hold (Team/Organization)

Public Hold (Community Registry)

Development/Testing

Production Deployment

Quick Production Checklist

Configuration Files Reference

Tags

Manifests

`HOLD_PUBLIC_URL` ⚠️ REQUIRED

`HOLD_SERVER_ADDR`

`HOLD_PUBLIC`

`STORAGE_DRIVER`

S3 Storage (when `STORAGE_DRIVER=s3`)

`AWS_ACCESS_KEY_ID` ⚠️ REQUIRED for S3

`AWS_SECRET_ACCESS_KEY` ⚠️ REQUIRED for S3

`AWS_REGION`

`S3_BUCKET` ⚠️ REQUIRED for S3

`S3_ENDPOINT`

Filesystem Storage (when `STORAGE_DRIVER=filesystem`)

`STORAGE_ROOT_DIR`

`HOLD_DATABASE_DIR`

`HOLD_KEY_PATH`

`HOLD_OWNER`

`HOLD_ALLOW_ALL_CREW`

`HOLD_BLUESKY_POSTS_ENABLED`

`HOLD_PROFILE_AVATAR`

`TEST_MODE`

`DISABLE_PRESIGNED_URLS`
